6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE

6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE

    • 6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE
    • 6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE
    • 6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE
    • 6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE
    • 6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE
    • 6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE
  • 6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE

    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: Octavia
    Certification: CE, FCC, RoHS
    Model Number: MR-C0614WXG-1042

    Payment & Shipping Terms:

    Minimum Order Quantity: 10pcs
    Price: $3.20-4.20USD/pc
    Packaging Details: Standard packing
    Delivery Time: 3-7days after the order is confirmed
    Payment Terms: T/T, PAYPAL, WEST UNION
    Supply Ability: 100000pcs/month
    Contact Now
    Detailed Product Description
    Model: MR-C0614WXG-1042 Sensor Size: 1/2.7''
    Mount: M12*0.5 Aperture: F1.4
    Focal Length: 6mm FOV: 56°x30.1°x65.2°(1/2.7")
    BFL: 0.1mm Dimension: φ14*17.29mm

    6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE



    Specification

    Model MR-C0614WXG-1042 Mount M12*0.5
    Focal Length 6mm Resolution 4.0MP
    Sensor Size 1/2.7" CRA 9.5°(1/2.7'')
    Aperture F1.4 BFL 5.74mm
    TTL 22.3mm Ilumination 42%(1/2.7'')
    Angle of View 56°x30.1°x65.2°(1/2.7") Distortion -6.5%(1/2.7")
    Application Starlight Lens





    6mm Lens with IR CUT for H.265 StarLight 3MP 3516C+Sony IMX291 Intelligent analysis IP Camera board ONVIF XMEYE



    Features:
    1. 4.0 megapixel Starlight HD Camera lens, 6mm F1.4 big aperture lens, Intelligent analysis IP Camera lens.
    2. 1/2.7" Format High quality cctv camera lens, optical lens ,M12 Mount Lens
    3. 6mm focal length 56 Degree of DFOV security lens
    4. Starlight Lens for Megapixel camera, Surveillance Lens, large aperture security Lens
    5. This high resolution cctv lens can capture the all resolution of mega pixel camera,IP camera & High resolution camera.



    Advantages and characteristics of lens:
    1. Day & Night
    With special design, IR series lenses make the portrait aberration lowest, and the focal planes for the visible and infrared light ranges almost the same, which means that the surveillance camera can deliver sharp images in both day and night applications.
    2. Flat Image
    With the use of advanced optical design technology, our lenses can get high definition and high contrast performance over the entire image field, from the center to the periphery. Also, these lenses are the most suitable for the image cut-out function of IP cameras.
    3. Multi Coating
    To minimize double image and flare present in backlight, multi coating is adhered to the lens surface. Hence, the lenses can show high contrast resolution performance even in backlight.
    4. High resolution lens
    The pixels of high resolution lenses are beyond 4.0 Megapixel,
    IR Cut and Lens Holder are available as per request.
