Diameter 8MM JB510 Long Wavelength Band Pass Filter/ZAB25/ZB1/QB5/QB23

Basic Information
Place of Origin: Shenzhen, China
Brand Name: Octavia
Certification: CE, FCC, RoHS, etc.
Model Number: MR-JB510
Minimum Order Quantity: 100pcs
Price: $4.5-5.5USD/pc
Packaging Details: Standard packing
Delivery Time: 3-7days after the order is confirmed
Payment Terms: T/T, PAYPAL, WEST UNION, L/C, etc.
Supply Ability: 100000pcs/month
Model: MR-JB510 Size: 8mm
Material: Glass Use: Optics
Thickness: 2mm Customize: Yes

Diameter 8MM JB510 Long Wavelength Band Pass Filter/ZAB25/ZB1/QB5/QB23



Diameter 8MM JB510 Long Wavelength Band Pass Filter/ZAB25/ZB1/QB5/QB23

We created a series of infrared band pass filters ,.We also accept the custom made.



JB510

Specification:

Diameter:8MM

Thickness:2MM

Dimension Tolerance:+/-0.15mm

Thickness Tolerance: +/-0.15mm

Surface Quality: 40-20

Clear Aperture: >90%





Diameter 8MM JB510 Long Wavelength Band Pass Filter/ZAB25/ZB1/QB5/QB23 1




Other iterms:

Part Number Diameter(mm)
Thickness
(mm)
λtj
(nm)
λ0
(nm)
Tλ0
(%)
K
LOHB600
25.4
2
600 ± 10
680
≥88.7
≥1.2
LOHB610
25.4
2
610 ± 10
680
≥88.7
≥1.2
LOHB630
25.4
2
630 ± 10
700
≥88.7
≥1.2
LOHB640
25.4
2
640 ± 10
720
≥88.7
≥1.2
LOHB650
25.4
2
650 ± 10
720
≥87.5
≥1.0
LOHB670
25.4
2
670 ± 10
750
≥87.5
≥1.0
LOHB685
25.4
2
685 ± 10
800
≥83.6
≥0.8
LOHB700
25.4
2
700 ± 10
800
≥79.8
≥0.8
LOHB720
25.4
3
720 ± 10
800
≥80.0
≥0.8
LOHB760 25.4 2 760± 10 850
≥83.6
≥0.6
LOHB800 25.4 2 800± 10 900
≥83.6
≥0.5
LOHB830 25.4 2 830± 10 930
≥83.6
≥0.5
LOHB850 25.4 2 850± 10 950
≥80.0
≥0.5
LOHB930 25.4 2 930± 10 1050
≥80.0
≥0.2

Diameter 8MM JB510 Long Wavelength Band Pass Filter/ZAB25/ZB1/QB5/QB23 2





Diameter 8MM JB510 Long Wavelength Band Pass Filter/ZAB25/ZB1/QB5/QB23 3

Diameter 8MM JB510 Long Wavelength Band Pass Filter/ZAB25/ZB1/QB5/QB23 4
