Home Products16MP/20MP FA Lens, Line scan lens16mm C VIS-NIR Series Fixed Focal Length Lens Long-wave infrared lens

16mm C VIS-NIR Series Fixed Focal Length Lens Long-wave infrared lens

16mm C VIS-NIR Series Fixed Focal Length Lens Long-wave infrared lens
16mm C VIS-NIR Series Fixed Focal Length Lens Long-wave infrared lens
Basic Information
Place of Origin: Shenzhen, China
Brand Name: Octavia
Model Number: MR-C1602BD-118
Minimum Order Quantity: 1
Price: $620USD/pc
Packaging Details: package in default
Delivery Time: 5-8 working days
Payment Terms: T/T
Supply Ability: 999pcs
Contact Now
Material: High-quality Optical Glass BFL: 13mm
MOD: 0.1M Coating: Anti-reflective Coating
Filter Screw Size: M28.5*0.5 Mount Type: C Mount
Image Size: 1/2''(6.48*5.16mm) Temperature Range: -10~50°C

16mm C VIS-NIR Series Fixed Focal Length Lens Long-wave infrared lens

Long-wave infrared lens
VISIBLE INFRARED LENS
This long-wave infrared lens is specially designed for SWIR chips IMX990/IMX991, covering visible light + near-infrared bands (400.1700nm)

This long-wave infrared lens uses ultra-low dispersion glass, which fully corrects focus shifts over an ultra-wide wavelength range
High transmittance, high uniformity
It is widely used in industrial sorting, color difference detection, food testing, medical, and other fields





Specification
Model MR-C1602BD-118 Mount C
Focal Length 16mm Resolution 8.0MP
Sensor Size 1/2''(6.48*5.16mm) Type Long-wave infrared lens
Aperture F1.8-16 Dimension Φ33.5*44.65mm
MOD 10cm Operating Temperature -10°C -- +50°C
Angle of View

22.44(H)*17.98(V)*28.14(D)

 BFL 13mm
Remark Metal Lens

HD 8MP 75mm CCTV Camera C Mount Lens Manual Iris Manual Focus F1.8 Aperture 1" Image Format Industrial Camera Lens: Specification Model MR-C7518W-8MP Mount C Focal Length 75mm Resolution 8.0MP Sensor Size 1/2.5'' Weight 138g Aperture F1.8 Dimension Φ36*65mm MOD 20cm Operating Temperature -20°C -- +60°C Angle of View 6.72°(HFOV) BFL 17.53mm Remark Metal Lens HD 8MP 75mm CCTV Camera C Mount Lens Manual Iris Manual Focus F1.8 Aperture 1" Image Format Industrial Camera Lens
